Dual USB-C Port Charging Power Delivery (PD) Outlet, 30 Watt, 20A, White

6 reviews   |   Q&A

$54.49

Free 4-Day Shipping!

Part #: T5835-W
Vendor: Leviton
In Stock!
Ships same business day from Boise, ID if ordered by 6pm EST
Ship To:
Check Arrival Date and Cost
Estimated Arrival
Estimated Cost
Maximum quantity available reached.

The Leviton T5835-W is a 20 Amp white decora outlet with two USB type-C charging ports that provide up to 2X the charging power with Power Delivery (PD) technology (no data transfer capability). With up to 30-Watt of charging power on each port, the T5835-W is the most advanced, powerful USB in-wall charger on the market. It supplies a higher level of power for faster charging of even power hungry laptops. With Smart Chip technology, the outlet recognizes and optimizes charging requirements to ensure each device gets the power level it needs to charge fast and efficiently.

Examples of maximum charging outputs are:
Single port connected to PD-enabled device: 15VDC@2A (30W) or 9VDC@3A (27W)
Single port connected to non-PD enabled device: 5VDC@3A (15W)
Both ports connected to devices (PD or non-PD): 5VDC@3A each (up to 30W total)

For added safety, the outlet features built-in overcurrent protection to prevent electronics from receiving too much power, which can damage the device. The internal thermo regulator also prevents electronics from overheating. The receptacle is Tamper-Resistant with built in shutters, so no harmful objects can get inside the outlet, improving child safety.

The outlet can be used for residential and commercial applications, making it a perfect choice for any duplex power requirements.

Color:  White
20 Amp outlet
2 USB-C charging ports
30W single port charging for PD-enabled device
15W single port charging for non-PD device
15W per port when both in use
Voltage: 125 VAC
Tamper resistant (TR) plugs
cCSAus listed
Decora size
NEMA: 5-20R
Side stainless terminals
Terminal wire with 14 or 12 AWG
Only 1.76" thick
Install using a licensed electrician
5 year warranty
Wallplate sold separately
Leviton T5835 Detailed Installation Instructions (PDF)
Leviton T5835 Information (PDF)


Color:  White
20 Amp outlet
2 USB-C charging ports
30W single port charging for PD-enabled device
15W single port charging for non-PD device
15W per port when both in use
Voltage: 125 VAC
Tamper resistant (TR) plugs
cCSAus listed
Decora size
NEMA: 5-20R
Side stainless terminals
Terminal wire with 14 or 12 AWG
Only 1.76" thick
Install using a licensed electrician
5 year warranty
Wallplate sold separately
Leviton T5835 Detailed Installation Instructions (PDF)
Leviton T5835 Information (PDF)
